RockShox Rudy Base XPLR 28″ Solo Air 40 Tapered

The new Rudy XPLR features Solo Air™ technology in combination with a rebound damper. Full compatibility with mudguards and generous tire clearance provide more options for exploring. It’s time to take the long way home.

Features – RockShox Rudy Base XPLR Solo Air

• Maxima Plush fluid reduces friction and damper noise
• Specially developed and designed for gravel and e-gravel bikes
• Cartridge damper with wide rebound adjustment range
• The Solo Air™ spring is perfectly tuned for shorter travel and efficiency over bumps
• Compatibility with short fenders with a 3-hole system
• Full fender compatibility with custom stealth mounts
• Maxima Plush damping fluid reduces friction and dampens damper noise
• Up to 700×50 tire clearance

Product features

• Application: Gravel
• Wheel size: 28″
• Model name: Base
• Suspension travel: 40 mm
• Suspension: Solo Air
• Shock type: Cartridge – Rebound Only
• Shock settings: Extl rebnd
• Steerer tube: Tapered 1.5″ to 1 1/8″ (tapered)
• Fork steerer length: 310 mm
• Stanchions: 30 mm
• Disc brake mount: Flat mount (direct flat mount 160 mm)
• Maximum recommended brake rotor size: 180 mm
• Dropouts: 12×100 mm Maxle Stealth thru axle
• Max. Tire diameter: 716 mm
• Max. Tire width: 50 mm
• Installation height: 435 mm
• Fork crown/head: 56 mm
• Offset: 51 mm
• Maximum recommended system weight: 135 kg
• E-bike approved: Yes
• ASTMF2043-EN17406 Class: 2

Steerer tube material

• Steerer tube: Aluminum
• Fork crown: Forged 7050 aluminum
• Stanchions: Tapered Wall Aluminum, Fast Black
• Downtubes: Magnesium

Color

• Gloss Black

Weight: approx

• approx. 1315 g

Scope of delivery

• 1 x RockShox Rudy Base XPLR Solo Air 40 mm Tapered (no box packaging)
• Rock Shox 12×100 mm Maxle Stealth thru axle

Flat mount mounting bolts and impact claw not included!
