Öhlins RXF36 m.2 Air TTX18 29″ 160 Tapered Boost

Fine-tuning at the highest level: Öhlins RXF36 m.2 with TTSC and Climb Mode

The Öhlins RXF36 m.2 Air TTX18 suspension fork combines the revised TTX18 cartridge from the DH38 Race Fork with an optimized 18 mm piston for precise control, improved traction and sensitive response on trail and enduro tracks. Its 3-chamber air spring with two pistons can be individually tuned over the entire spring travel using the Total Tune Spring Curve System (TTSC) – from response to the end stop.

The fork offers 15 clicks for low-speed rebound and compression and 3 clicks for high-speed compression, including climb mode for customizable riding dynamics. Its stiff and lightweight chassis ensures precise handling on demanding trails. This makes the RXF36 m.2 the perfect choice for riders looking for maximum performance with individual adjustability.

Features – Öhlins RXF36 m.2 Air TTX18

• TTX18 cartridge technology from the DH38 RACE FORK for improved control, traction and sensitive response on trails and in enduro races.
• Optimized damping system with 15 clicks of low-speed rebound and compression damping, 3 clicks of high-speed compression damping and Climb Mode for maximum customization.
• Three-chamber air spring with two-piston system including Total Tune Spring Curve System (TTSC) for precise tuning over the entire spring travel.
• Stiffer, lighter and more compact chassis, ideal for demanding gravity trails and E-MTBs.
• Excellent traction and damping performance, even on technically demanding trails – effectively absorbs roots and rocks for more comfort and control.

Product features

• Use: MTB, Trail, Enduro
• Model designator: RXF36 m.2 Air TTX18
• Wheel Size: 29″
• Stroke: 160 mm
• Damping adjustments: Spring rate and progression, 15-click rebound damping, 15-click low speed compression damping, 3-click high speed compression damping, Climb mode
• Steerer: Tapered 1.5″ to 1 1/8″
• Steerer Length: 230 mm
• Stanchions Tubes: 36 mm
• Disc Brake Mount: Post Mount
• Drop Out: 15×110 mm Boost
• Max Tire Width: 66 mm
• Axle To Crown: 585 mm
• Offset: 51 mm

Material

• Aluminum

Weight

• approx. 2050 g

Scope of delivery

• Öhlins RXF36 m.2 Air TTX18 29″ 160 Tapered Boost (no box packaging)
• 15×110 mm Boost thru axle
